ENiQ Guard Compact Slimline mit Rosette Set - Digital Handles

About

Meet the Guard - proof that a product can be strong and durable, without renouncing a sleek and stylish design. Our digital door fittings from the ENiQ line, secure every door and at the same time look stylish. The guard is ideal for office and administration buildings, hospitals/clinics/elderly homes, banks and hotels, public facilities (shopping centres and restaurants) and schools and universities.

Benefits

Complete digital handle portfolio. Available as Slimline, Wideline and Compact version with one or two-sided readability or as purely mechanical fitting.
The assembly of the Guard is an effortless undertaking.
Suitable for all Europrofile cylinders and door thicknesses.
Visual and acoustic signalisation lets you know immediately if you have access rights.
Easy battery change and long life due to long standby time and large number of locking cycles per battery.
The Guard is available in 3 colors and with its sleek and stylish appearance, complements any interior.
Robust handle with strong resistance to vandalism.
The ENiQ Guard is part of the ENiQ Security Ecosystem and easy to integrate with other digital DOM products from the ENiQ range.

IP54: protection from limited dust ingress and against water splashed from all directions; limited water ingress permitted and shall have no harmful effect

Suggested application of use

Airports, Education, Financial, Homes, Hospitals, Hotels, Industrial, Medium to Large Sized Businesses, Offices, Plants, Public Buildings, Small to Medium Sized Businesses

Specifications

Technical features

Fire Resistant	90 Minutes
Water Resistant	No
Patent Protection	Yes
Anti Corrosion Protection	Yes
Communication Technology	BLE 5.0, RFID 13.56 MHz, NFC
Stand-alone Functionality	Yes
Data On Card	Yes
User Identification Technology	BLE 5.0, RFID 13.56 MHz, NFC
Number of Inputs	2
Number of Outputs	0
Acoustic Signalling	Yes
Optical Signalling	Yes
Supported Locking Media	Mifare Classic, Mifare DESFire, Mifare DESFire 8k, Mifare Ultralight, Mifare Plus, ISO 14443 A, Legic ATC 1024
Programming Methods	Master Card, Programming Card, Software, Smartphone
Battery Type	AAA Lithium
Number of Batteries	2
Battery Lifetime Years	Up to 3 Years
Battery Warning Alarm	Audio, Visual
Standard Warranty	1 Year
Maximum Operating Temperature (celsius)	65
Maximum Relative Humidity (%)	99
Maximum Storage Temperature (celsius)	65
Minimum Operating Temperature	-25
Minimum Storage Temperature (celsius)	-25

Certifications

Patent Protection	Yes
Patented Until (year)	2038
Ingress Protection Rating	IP54
EN 179:2008	In Testing

Configuration

Surface Finish	Brushed Stainless Steel, Black, White, Grey
Fixation Type	Screw on or screw through
Handle Types	L-Shape mitre, L-Shape curved, U-Shape mitre, U-Shape curved, Cranked curved, Cranked mitre, Ball mitre only outside, L-Shape mitre + ball, L-Shape curved + ball, U-Shape mitre + ball, U-Shape curved + ball, Cranked mitre + ball, Cranked curved + ball
Power Type	Battery
Events Storage Capacity in the Device	2000
RFID Encryption	AES, AES-128 Bit, DES, 3DES, Crypto-1, ISO 14443A, OSS
Data Encryption	XSALSA20-256 Bit, Curve 25519-256 Bit, Poly 1305-128 Bit
Operating Temperature (Celsius)	-25° to 65°
Input Options	Door open, lock status, ect.
Assembly Information	Flexible Fixation Points due to movable sleeves/screws

Optional Accessories

Silicon Labs BLED112 V1

352357

ENiQ Starter package Guard

352399

Master card, programming card, battery change card, Torx screwdriver TX 10

Batteries 10 pieces per box

352356

Battery for the Guard

Mounting tool Hook bush

518841C032

Required for mounting and dismounting of hook bushes

Silicon Labs BLED112 V1 with Wake Up Card

352460

ENiQ RF NetManager V2

The ENiQ RF NetManager is a communication module to connect the products in the doors, like the ENiQ...

ENiQ Standard Tag

STANTAC504599M

ENiQ Premium Plus Tag

PREMPLUSTAC504599M

ENiQ Combined Transponder Standard Tag

STANTAC504599M

ENiQ Clip Tag V2

ENiQ ISO Cheque Card Transponder

ISOSCHE503523M

Building Locking Card

Function test of the devices in the installation state before the master card is created.

Related Software

DOMConnect App

ENiQ AccessManagement Software

The new software has been developed as a single administrative platform for the DOM ENiQ® Mifare fam...

DOM ENiQ App

With the DOM ENiQ app you have a full access management programming tool in your pocket.

ENiQ Guard Digital reader for access control of your door for opening and locking with 13.56 MHz Mifare RFID transponders, as well as with smartphones via Near-Field-Communication (NFC) and Bluetooth Low Energy (BLE) in the DOM ENiQ product world.
