Coworking Spaces, Education, Hospitals, Hotels, Industrial, Medium to Large Sized Businesses, Offices, Plants, Public Buildings, Small to Medium Sized Businesses
| Lock Application Type | Mortise Lock |
| Locking Points | Single Point |
| Locking Type | Single Bitted Key Lock |
| Closing Mechanism | Step Mechanical |
| Locking Elements | Deadbolt and Magnetic Latch |
| Deadbolt Operation | Standard |
| Latch Type | Magnetic |
| Lock Handing | Universal (Standard & Reverse) |
| Key Turns | 1 |
| Compatible with Electric Strike | No |
| Number of Keys | 2 |
| Key Material | Zamak |
| Interaxis (mm) | 70 |
| Backset Inc Forend (mm) | 40, 50 |
| Case Height (mm) | 134 |
| Case Depth (mm) | 76.5 |
| Case Width (mm) | |
| Case Thickness (mm) | 13 |
| Case Material | Steel |
| Case Finish | Galvanised |
| Deadbolt Shape | Rectangular |
| Deadbolt Material | Steel & Zamak |
| Deadbolt Dimension | 40.5 x 8 mm |
| Deadbolt Throw (mm) | 14 |
| Latch Throw (mm) | 11 |
| Latch Material | POM |
| Follower Type | Standard Follower |
| Follower (mm) | 7 |
| Material of the Follower | Zamak |
| Forend Type | Round |
| Forend Shape | Flat |
| Forend Length (mm) | 230 |
| Forend Thickness (mm) | 3 |
| Forend Width (mm) | 20 |
| Forend Material | Stainless Steel |
| Forend Finish | Brushed |
| Strike Plate Included | Yes |
| Lock Handing | Universal (Standard & Reverse) |
