With its floating mounted dual role within the key the new reversible key system ix Twintec provides a high protection against unauthorised key copying. The complex system of 11 active locking elements has been desgined for use as a registered individual locks for the home or as a small masterkey system for small to medium sized businesses.
Property rights: patent term 2036
Floating mounted dual role within the key
Certifications:
- DIN EN 1303 with the highest ranking in Attack Resistance
- SKG 2*
- SKG 3* (optional)
Modular cylinders, Highest level of drilling & pull protection
Compatibility with protective rosettes due to the flat key design
Extended key neck lenght for better fitment with security fittings
Available with a plastic key head for ergonomic handling
Compatibility to electronic locking systems with ClipTag
Airports, Education, Financial, Homes, Hospitals, Industrial, Medium to Large Sized Businesses, Offices, Plants, Public Buildings, Small to Medium Sized Businesses, Hotels
| Fire Resistant | Yes |
| Trademark Protection | Yes |
| Key Type | Reversible Key Systems |
| Registration Card | Yes |
| Total Number of Locking Elements | 20 |
| MKS Possibilities | Master Key, Single Coded |
| Anti Pick Protection | Yes |
| Anti Bump Protection | Yes |
| Anti Drill Protection Housing | Yes |
| Anti Drill Core Protection | Yes |
| Anti Pull Protection | Yes |
| Modular | Yes |
| 2 in 1 Function | Optional |
| Available as a Service Cylinder | N/A |
| Maximum Number of Lateral Elements | 10 |
| Maximum Number of Upper Elements | 9 |
| Number of Active Locking Elements | 10 |
| Number of Ant Bumping Elements | 8 |
| Number of Anti Picking Elements | 8 |
| Number of Moveable Elements | 2 |
| Number of Passive Elements | 10 |
| Standard Warranty | 3 Years |
| Standard Finish | Matt Nickel |
| Standard Housing Material | Brass |
| EN 1303:2015 | 160B0A6D |
| SKG Star Rating | 3 * |
| Key Patent Protection | Yes |
| Key Patent Until (year) | 2036 |
| System Patent Protection | Yes |
| System Patented Until (year) | 2036 |
| Trademark Protection | Yes |
| Number of Keys | 5 |
| Key Material | New Silver |
| Standard Finish | Matt Nickel |
| Optional Finishes | Matt Brass, Black |
| Standard Housing Material | Brass |
| Standard Cam | DIN |
| Optional Cams | Spanish Cam, 10 Teeth Gear Cams, 14 Teeth Gear Cams |
